Domain model in ooad examples. Object oriented analysis design ooad i domain modeling introduction cs577a fall 2006 developed by david klappholz stevens institute of technology supannika koolmanojwong usc center for software engineering ed colbert usc center for software engineering. The quintessential object oriented analysis step is the decomposition of a domain into noteworthy concepts or objects. Thus it has also been called a conceptual object model. A domain model is a visual representation of conceptual classes or real situation objects in a domain m095 fowler96 domain models have also been called conceptual models the term used in the first edition of this book domain object models and analysis object models.

Let us consider a simple class circle that represents the geometrical figure. Features of a domain model domain classes each domain class denotes a type of object. This model illustrates the noteworthy concepts player die and dicegame with their associations and attributes. Examples of domains include.

Figure 1 3 partial domain model of the dice game. Each instance of the class separately holds a value. Illustrates meaningful concepts in the problem domain. No operations are defined or specified in the domain model.

Library domain model bank account class diagram example online shopping domain model health insurance policy uml class diagram example. Slide 36 of 138. The model shows concepts associations. In this chapter we will look into the basic concepts and terminologies of object oriented systems.

Note that a domain model is not a description of software objects. Attributes an attribute is the description of a named slot of a specified type in a domain class. For example a partial domain model is shown in figure 1 3. This document is highly rated by it software students and has been viewed 1986 times.

Object oriented analysis design ooad domain modeling introduction 1. The object model visualizes the elements in a software application in terms of objects. Examples of uml diagrams website atm online shopping library management single sign on sso for google apps etc. Science engineering medecine business government military a domain model is a package containing class and activity diagrams.

Not software components of the system under development. It is a visualization of the concepts or mental models of a real world domain. Ooad object model. Is a representation of real world things.
